Semi-Solid State 30000mAh 22.2V 5C 6S1P G-Tech Lipo Battery Pack with XT90-S plug

The Tattu Semi-solid state 30000mAh 22.2V 5C 6S1P LiPo battery is a revolutionary semi-solid lithium battery, featuring high energy density and long service life. It is an ideal power solution for various industrial drones, including those used in mapping, inspection, surveying, delivery, and eVTOL applications. These drones typically require a nominal discharge current of 1-3C, and this battery’s lightweight design, compact size, and extended flight time fully meet those demands.

Specifications:

1. Capacity: 30000mAh
2. Voltage: 22.2V/6S
3. Max Constant Current: 3C
4. Max Peak Current: 5C
5. Net Weight: 2525g (±20g)
6. Size: 206*90*65mm
7. Discharge Connector Type: XT90-S
8. Balancer Connector Type: G-Tech-7P
9. Energy Density: 284.62Wh/kg
10. Voltage Range: From 4.2V to 2.75V when SOC is from 100% to 0%
11. Cycle Life: Over 500 cycles

Technical Features:

1. Ultra-High Nickel Technology: Likely contributes to higher energy density and overall battery performance.
2. Silicon Carbon Anode: Enhances the battery’s capacity and cycling stability.
3. Coated Diaphragm Technology: Improves safety and performance by enhancing the separator's strength and stability.
4. Solid Electrolyte: Offers improved safety and performance, reducing the risk of leakage and enhancing the battery's life.
