Overview

From the innovative labs at FXLION comes the world’s most compact V-Mount batteries for video and motion picture production. Lighten up your carrying load, charge anywhere, and power almost all of your gear. The NANO ONE is a 50Wh lithium ion battery that weighs in at only 11 ounces taking a load off your gear and your back.

Charge your NANO batteries anywhere with your mobile* device charger via the Micro-USB and USB-C ports or through its D-Tap port or V-Mount charger. Use select ports to power your lights, camera, smart phone, USB-C laptops, and video accessories. Purposely designed accessory plates adapt the NANO series batteries to fit a multitude of rigging and power needs. The NANO battery gives the power you need in the palm of your hand.

Features

• LCD display for capacity and voltage
• Internal cell protection & hard plastic casing
• PCB Design: Over-Heat, Over-Charge, Over-Discharge, and Over-Current Protection
• Compatible with V-Lock, D-Tap, and tablet/laptop* USB charger
• Flight friendly in carry on luggage

*Some low voltage phone / tablet chargers may not be sufficient to charge the battery to full capacity. For USB C charging, a 20V/2.2A output charger (44W) is optimal.

Tech Specs

Physical Specs

• V-Mount battery interface
• Capacity:  3.4Ah, 50Wh
• D-Tap Outputs: 1
• USB A Outputs: 1
• USB C Input/Output: 1
• USB Micro Inputs: 1
• Physical Dimensions: 100 x 71 x 35mm (3.94 x 2.80 x 1.38")
• Weight (in use): 310g / 0.7lb

Electrical Specs

• D-Tap Output: 14.8V
• USB A Output: 5V/2.4A, 9V/2A, 12V/1.5A
• USB C Input/Output: 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/2.2A
• USB Micro Input (only): 5V/3A

Charging Time

• V-lock/D-Tap charger(16.8V/2A): ~2 hours
• 18-30W PD Type-C fast charger: ~2.5-4 hours
• Micro USB charger(5V/2A): ~7.5 hours

Compatibility

• FXLION Nano V-Mount
• Ember S5K with optional Ember Cheese Plate and FXLION Nano V-Mount
• Pilot Pro for Astro, Astro Max, Alta X, or Alta X Gen2 with optional V-Mount Battery Plate Kit

Shipping Considerations

• Batteries cannot be shipped internationally via UPS. FedEx only.
• Due to extra processing time at FedEx, shipping times are not guaranteed for hazardous goods.
